Corvette Z06 Track Alignment & Tire Guide: C7 & C8 Setup

C7 vs C8: Different Weight Distribution

The C7 Z06 is front-engine with significant nose weight. The C8 Z06 is mid-engine with more rear weight bias. Track alignment settings differ — C8 can run more rear camber; C7 needs more front camber to manage understeer on entry.

Track Alignment Starting Points

Refer to the points below for specs, intervals, and service tips.

  • C7 Z06: -2.5° front, -2.0° rear camber (200TW tires)
  • C8 Z06: -2.5° to -3.0° front, -2.0° to -2.5° rear
  • Toe: slight toe-out front for turn-in on both generations
  • Reset to street alignment after track weekends

Tire and Brake Wear Correlation

Uneven tire wear and brake pad taper often indicate the same root cause — alignment, bushing wear, or a sticking caliper. Inspect all four caliper slide pins when you notice inside-edge tire wear on a track-used Z06.

Learn more in our Corvette brake pads guide.

Alignment and Brakes Share the Contact Patch

2-piece drilled and slotted rotors for even pad wear under track camber.
